ORBAsec SL3 3.5.0

ORBAsec SL3 adds authentication and encryption to Adiron's AdironORB, a source-available ORB, and IONA's ORBacus for Java ORB.

ORBAsec SL3 brings you both TLS/SSL and both Windows 2000 Kerberos and MIT Kerberos interoperability.

ORBAsec SL3 also brings you Kerberos User-to-User protocol that allows you to set up servers based on Kerberos login credentials.

ORBAsec SL3 gives you the OMG and EJB standard CSIv2 protocol which allows you to perform identity delegation over these cryptographic technologies to enhance your secure capabilities.

Introduction

ORBAsec SL3 is an ongoing implementation of the Common Secure Interoperability Version 2 (CSIv2) Protocol

ORBAsec SL3 implements the Authorization Token Layer Acquisition Service (ATLAS) part of the CSIv2 protocol.

The documentation presented in this HTML directory is the preliminary documentation for an Application Programming Interface (API) for enabling the use of the OMG CSIv2 Protocol in CORBA applications. The API presented here is not the standard CORBA Security Level 2 API. The standard CORBA Security Level 2 API is extremely insufficient for enabling the use of the CSIv2 Protocol. Instead, Adiron has created a brand new API.

This new API is based on a mathematical model and calculus regarding Principals, which can be found in the following paper: Authentication in Distributed Systems: Theory and Practice by Lampson, Abadi, and Burrows.

A Principal is an entity that is either a person, a server, etc. that is referred to by a name. A principal may be authenticated by virtue of cryptographic means, such as the use of SSL/TLS, or other authentication mechanism. A principal may be anonymous.

We have named this new API SecurityLevel3 under "adiron.com". This API is a much more robust API than OMG's Security Level 2 API, and has well defined semantics. We will, in time, push to have the OMG standardize on much of this API, as it does have a basis in mathematics, and therefore, gives credibility to a security API.

CSIv2 - Common Secure Interoperability Version 2

Both of these layers interact in such a way to give security contexts that can be lasting over connections, or as good as only one request over a long-standing connection.

The Transport Layer - CSIv1

The Transport Layer is basically Common Security Interoperability Version 1. Version 1 handled security down at the transport layer, i.e. closely wrapped around TCP/IP. It covers the secure establishment of the connection from client to server.

In a regular ORB, the transport layer is the ORB protocol, General Inter-ORB Protocol (GIOP) over TCP/IP. This protocol is commonly known as IIOP. In CSIv1, IIOP and two other protocols exist, SSLIOP and SECIOP. SSLIOP defines the transport layer as using SSL (now known as TLS) over TCP/IP. So, GIOP over TLS over TCP/IP is known as SSLIOP. The OMG defines its own SSL-like transport protocol for dealing with General Security Services API (GSS-API) from the IETF. This protocol is known as SECP. GIOP over SECP over TCP/IP is known as SECIOP.

Before messages start flowing freely over the communication channel between ORBs, the secure TLS, or SECP endpoints negotiate the channel protection, such as encryption and integrity checking. They also exchange enough information to authenticate the endpoints to one another, by virtue of exchanging cryptographic keys and signatures.

The CSIv2 Layer - GIOP Service Contexts

The CSIv2 layer is run on top of the transport layer and its information is carried in the Service Context of GIOP Request and Reply messages. The CSIv2 layer is composed of three parts.

Each of these layers is actually a piece of a single CSI GIOP Service Context Element that flows with a request. They work together and combine to tell the server who and with what privileges the GIOP request is being made.

The Client Authentication Layer

The Client Authentication Layer provides an extra layer of authentication. Is provides for the delivery of an authentication token, or cookie, to the server. This cookie merely tells the server that its holder is in possession of proven authentication and identity information. The reason for the existence of this layer is that TLS does not require a client to authenticate to a server. For example, to authenticate at the transport layer in TLS requires the client to possess an X.509 certificate. The Client may only have a notion of using a username and a password. ORBAsec SL3 supports a Username/Password scheme at this layer.

The Identity Assertion Layer

The Identity Assertion Layer allows a client to merely state that the request being made is on some other entity's behalf. An application using this feature is usually an intermediate server. For instance, let's say Bob, has gotten a request from an authenticated client, Alice, using TLS. Bob needs to contact another CORBA object, Carol, and make a request, not as Bob, but as the original client, Alice. There is an agreement between the intermediate server, Bob, and the final target, Carol, such that Bob will simply state under which principal the request is being made. Carol will act accordingly based on that information. Carol interprets this information as "Bob says Alice is making this request".

The Authorization Layer

The Authorization Layer is a layer that enables the delivery of an authorization token from the client to the server. This layer implements a push model for authorization. The client, Alice, may get and cache her authorization information as not to overburden a heavy server, Bob, the task of looking up Alice's credentials for each request. This token might contain such things as a verifiable certificate claiming that Alice has certain privileges on which Bob may make trust decisions. ORBAsec SL3 uses the standard Authorization Token Layer Acquisition Service (ATLAS) to implement both ends of the authorization layer.

The Security Level 3 API

The Security Level 3 API is the heart of ORBAsec SL3's CSIv2 implementation. It carries common data structures, such as PrincipalName, PrinAttribute, Principal, and other such data structures that implement a model of principals closely resembling the mathematical model and calculus found in the following paper: Authentication in Distributed Systems: Theory and Practice by Lampson, Abadi, and Burrows.

The Security Level 3 API can be said to be divided up into three separate yet intertwined models.

The Administrative model contains interfaces that deal with the maintenance of the Security Level 3 entities. There is a SecurityManager, CredentialsCurator, CredentialsAcquirer, and helper objects. The Credentials Model, entities of which emanate from the objects in the Administrative model, handle the establishment of secure associations between clients and targets, and abstract away the use of cryptographic protocols. The Principals Model consists of structured data types, used in the Credentials model entities, to represent the principals involved in secure associations.

The Security Level 3 Administrative Model

The SecurityManager is the Security Level 3 Service object that is retrieved from the ORB using the resolve_initial_references("SecurityLevel3:SecurityManager") call. The Security Manager, containing a reference to the CredentialsCurator, has some operations for creating security relevant policies, and an operation to discover the credentials of a target object.

The CredentialsCurator is an object that creates credentials, by way of CredentialsAcquirer objects, and maintains lists of active credentials for the ORB's security service. It creates Credentials that operate the CSIv2 Layer and the Transport Security Layer together, as if they were married. The acquisition of Credentials is a complex business. Many parameters go into acquiring credentials, such as transport security options: port numbers, IP addresses, X.509 Private keys and certificates, etc., and CSI options, such as a TrustDecider, and Username/Password processors, and authorization processors, i.e. ATLAS.

To help with this business of Credentials Acquisition, ORBAsec SL3 has created the SL3 Argument Factory, which is located in the SL3AQArgs module. This object handles the building of the acquisition argument that is given to the Credentials Curator to create Credentials, through the use of an ArgBuilder objects. These objects are extended by interfaces in other modules that create options specific for their purposes, such as using TLS with Java KeyStores, or Kerberos with the JAAS framework.

The SecurityCurrent is a Current object that is used on the server side. It contains operations that retrieve a representation of the client's credentials during the execution of a request.

The Security Level 3 Credentials Model

The Security Level 3 Principals Model

In the Security Level 3 Principals model, a Principal comes in three types. A SimplePrincipal merely states a request, i.e. (A says r). A QuotingPrincipal merely states another principal is making a request, i.e. (A says B says r), and is usually denoted with a vertical bar, as in (A|B) for "A quotes B". And finally, a ProxyPrincipal is almost the same as a QuotingPrincipal, however, it is a little stronger than a QuotingPrincipal in that B may have given A something to use, such as an authenticator, or a certificate claiming that if (A says B says r) then A is allowed to speak on behalf of B. The difference is subtle.

All the Principals are valuetypes with simplistic factory operations. They can be shipped across to other objects, such as Access Decision objects, etc, for analysis, access control, auditing, etc. This model is the data model of ORBAsec SL3.

Transport Security API

The Transport Security Administrative Model

The Transport Security Credentials Model

The implementation of the Security Level 3 API actually uses an extended Transport Security API in dealing with the transport. The Transport Security API is also extended so that it may be replaceable. Replaceability allows other secure transports, i.e. other than TLS, to be implemented and installed into ORBAsec SL3, such as SECIOP-GSS-KerberosV5.

Getting ORBAsec SL3 Started with AdironORB

The first thing you need to do to get started with ORBAsec SL3 with AdironORB is to initialize the ORB with ORBAsec SL3's initializers. There are two different ways to initialize the ORB with ORBAsec SL3, one if your application is going to be pure client, and the other if your application is going to be a server. This means without bringing up the Root POA (Portable Object Adapter) and one if you are going to be a server, i.e. reference the Root POA.

Client initialization is performed as follows:

java.util.Properties props = System.getProperties();
props.put("org.omg.CORBA.ORBClass", "com.adiron.orb.core.ORB");
props.put("org.omg.CORBA.ORBSingletonClass",
          "com.adiron.orb.core.ORBSingleton");
props.put("org.adiron.orb.server.enable","false");
props.put("org.adiron.orb.ORBInitializerClass",
          "com.adiron.orbasec.sl3.AdironORBInitializer");
props.put("org.omg.PortableInterceptor.ORBInitializerClass." +
          "com.adiron.orbasec.sl3.SL3Initializer_AdironORB", "");
org.omg.CORBA.ORB orb = org.omg.CORBA.ORB.init(args, props);

The first two properties select the ORB you will be working with, which is AdironORB. The next property, org.adiron.orb.server.enable, determines whether the ORB will be used for server applications. For a client application, this property is set to false.

The next property, org.adiron.orb.ORBInitializerClass, specifying the AdironORB internal initializer, is set to com.adiron.orbasec.sl3.AdironORBInitializer for using ORBAsec SL3's secure network communications. The last property, starting with org.omg.PortableInterceptor.ORBInitializerClass, installs ORBAsec SL3 into the Adiron ORB by way of Portable Interceptors.

Server initialization is basically the same except that we change the value of the org.adiron.orb.server.enable property to true. Server initialization is performed as follows:

java.util.Properties props = System.getProperties();
props.put("org.omg.CORBA.ORBClass", "com.adiron.orb.core.ORB");
props.put("org.omg.CORBA.ORBSingletonClass",
          "com.adiron.orb.core.ORBSingleton");
props.put("org.adiron.orb.server.enable","true");
props.put("org.adiron.orb.ORBInitializerClass",
          "com.adiron.orbasec.sl3.AdironORBInitializer");
props.put("org.omg.PortableInterceptor.ORBInitializerClass." +
          "com.adiron.orbasec.sl3.SL3Initializer_AdironORB", "");
org.omg.CORBA.ORB orb = org.omg.CORBA.ORB.init(args, props);

You need the server initialization if you are going to access the Root POA using the orb.resolve_initial_references("RootPOA") call and perform object._this(orb) calls, which "registers" an object implementation with the ORB's POAs.

Getting ORBAsec SL3 Started with ORBacus

Client initialization is performed as follows:

java.util.Properties props = System.getProperties();
props.put("org.omg.CORBA.ORBClass", "com.ooc.CORBA.ORB");
props.put("org.omg.CORBA.ORBSingletonClass",
          "com.ooc.CORBA.ORBSingleton");
props.put("ooc.oci.plugin.iiop","com.adiron.orbasec.sl3.IIOP");
props.put("org.omg.PortableInterceptor.ORBInitializerClass." +
          "com.adiron.orbasec.sl3.ClientInitializer", "");
org.omg.CORBA.ORB orb = org.omg.CORBA.ORB.init(args, props);

The first two properties select the ORB you will be working with, which is ORBacus. The next property, ooc.oci.plugin.iiop, specifying the IIOP plug-in class, is set to com.adiron.orbasec.sl3.IIOP for using ORBAsec SL3's secure network communications instead of ORBacus' "insecure" IIOP communications. The next property installs ORBAsec SL3 into the ORBacus ORB by way of Portable Interceptors, which is an ORB initialization interceptor. We use the class com.adiron.orbasec.sl3.ClientInitializer to initialize a client.

Server initialization is basically the same except that we use a different initializer, com.adiron.orbasec.sl3.ServerInitializer. Server initialization is performed as follows:

java.util.Properties props = System.getProperties();
props.put("org.omg.CORBA.ORBClass", "com.ooc.CORBA.ORB");
props.put("org.omg.CORBA.ORBSingletonClass",
          "com.ooc.CORBA.ORBSingleton");
props.put("ooc.oci.plugin.iiop","com.adiron.orbasec.sl3.IIOP");
props.put("org.omg.PortableInterceptor.ORBInitializerClass." +
          "com.adiron.orbasec.sl3.ServerInitializer", "");
org.omg.CORBA.ORB orb = org.omg.CORBA.ORB.init(args, props);

You need the server initialization if you are going to access the Root POA using the orb.resolve_initial_references("RootPOA") call and perform object._this(orb) calls, which "registers" an object implementation with the ORB's POAs.

Special notes for previous users (ORBAsec SL3 3.4.0 and before)

Basic ORBAsec SL3 Credentials Acquisition Procedure

The basic procedure for using Security Level 3 API to create CSIv2 enabled Credentials or Transport Security API to create CSIv1 transport Credentials is similar, but creating CSIv2 enabled credentials involves more steps.

The acquisition process for creating CSIv1 transport Credentials is as follows:

1. Get the Transport Security Security Manager service object from the ORB, i.e. calling resolve_initial_references("TransportSecurity:SecurityManager").
2. Get the Transport Security Credentials Curator from the Security Manager.
3. Get the appropriate Transport Security ArgumentFactory service object from the ORB, e.g., resolve_initial_references("SL3TLS:ArgumentFactory").
4. Create an Acquisition Argument Builder object from the ArgumentFactory.
5. Add appropriate options to the Argument Builder to acquire Transport Security Credentials.
6. Reap the argument from the Argument Builder and hand it to the Transport Security Credentials Curator for acquiring Transport Security Credentials. These actions will return a Transport Security Credentials Acquirer object.
7. Call get_credentials on the Credential Acquirer object to get the Transport Security Credentials object.

The acquisition process for creating CSIv2 Credentials is as follows:

1. Get the Security Level 3 Security Manager service object from the ORB, i.e. calling resolve_initial_references("SecurityLevel3:SecurityManager").
2. Get the Security Level 3 Credentials Curator from the Security Manager.
3. Get the appropriate Transport Security Argument Factory service object from the ORB, e.g., calling resolve_initial_references("SL3TLS:ArgumentFactory").
4. Create an Acquisition Argument Builder object from the Argument Factory.
5. Add appropriate options to the Argument Builder to acquire Transport Security Credentials.
6. Reap the Transport Security argument from the Argument Builder for later use.
7. Get the CSI Argument Factory service object from the ORB, e.g., calling resolve_initial_references("SL3CSI:ArgumentFactory").
8. Create a CSI Argument Builder object from the CSI Argument Factory.
9. Add the Transport Security argument to the CSI Argument Builder, along with other CSI acquisition parameters.
10. Reap the argument from the CSI Argument Builder and hand it to the Security Level 3 Credentials Curator for acquiring Security Level 3 Credentials. These actions will return a Security Level 3 Credentials Acquirer object.
11. Call get_credentials on the Credentials Acquirer object to get the Security Level 3 Credentials object.

We illustrate one specific method of acquiring Security Level 3 (i.e. CSIv2) with TLS for a Server, by the Java code below:

public com.adiron.SecurityLevel3.OwnCredentials
createDefaultSL3TLSCredentials(org.omg.CORBA.ORB orb)
    throws org.omg.CORBA.UserException
{
  //
  // Resolve the Security Level 3 Security Manager
  //
  com.adiron.SecurityLevel3.SecurityManager secManager =
      com.adiron.SecurityLevel3.SecurityManagerHelper.narrow(
          orb.resolve_initial_references(
              "SecurityLevel3:SecurityManager"));

  //
  // Get the Credentials Curator from the Security Manager
  //
  com.adiron.SecurityLevel3.CredentialsCurator curator =
      secManager.credentials_curator();

  //
  // Resolve the TLS Transport Argument Factory
  //
  com.adiron.SL3TLS.ArgumentFactory argFac =
      com.adiron.SL3TLS.ArgumentFactoryHelper.narrow(
          orb.resolve_initial_references("SL3TLS:ArgumentFactory") );

  //
  // Get a TLS KeyStore based Transport Argument Builder for a Server.
  //
  com.adiron.SL3TLS.TLSKeyStoreArgBuilder tlsArgBuilder =
      argFac.createTLSKeyStoreArgBuilder(
          com.adiron.TransportSecurity.CU_AcceptOnly.value );

  //
  // Add TLS KeyStore parameters for initializing TLS Transport
  // Security Credentials.
  //
  // The TCPIP (socket) parameters will be left to the defaults.
  //
  tlsArgBuilder.addTLSKeyStoreWithStorePass(
      "FILE:demo.keystore",          // keystore URL
      "IAIKKeyStore",                // storetype
      "mystorepass",                 // storetpye
      "marge",                       // keyalias
      "mypassword",                  // keypass
      new String[] {"SpringfieldCA"} // trusted_cert_names
  );

  //
  // Resolve the CSI Argument Factory
  //
  com.adiron.SL3CSI.ArgumentFactory csiArgFac =
      com.adiron.SL3CSI.ArgumentFactoryHelper.narrow(
          orb.resolve_initial_references("SL3CSI:ArgumentFactory") );

  //
  // Get an Argument Builder for Security Level 3 Credentials for a Server
  //
  com.adiron.SL3CSI.CSIArgBuilder csiArgBuilder =
      csiArgFac.createCSIArgBuilder(
          com.adiron.SecurityLevel3.CU_AcceptOnly.value );

  //
  // Add the Transport Argument to the CSI Argument Builder
  //
  csiArgBuilder.addTransportCredentialsAQArgs(
          com.adiron.SL3TLS.MID_TLS.value,
          com.adiron.SL3TLS.AQM_TLSArgs.value,
          tlsArgBuilder.reapAQArg() );

  //
  // Reap the CSI Acquisition Argument from the Builder
  // and acquire the credentials.
  //
  com.adiron.SecurityLevel3.CredentialsAcquirer acquirer =
      curator.acquire_credentials(
          com.adiron.SL3CSI.AQM_CSIArgs.value,
          csiArgBuilder.reapAQArg() );

  //
  // Get the Credentials. True means put them on the
  // default own credentials list for accepting invocations.
  //
  com.adiron.SecurityLevel3.OwnCredentials own =
      acquirer.get_credentials(true);

  return own;
}

Transport Security Credentials (CSIv1):

SL3TCPIP - options for TCP/IP socket parameters.

SL3TLS - options for acquiring TLS Credentials

SL3KRB5 - options for acquiring Kerberos Credentials

Security Level 3 Credentials (CSIv2):

SL3CSI - options for acquiring the Security Level 3 (CSIv2) Credentials

Scenarios in Demonstration Programs

Please review the demonstration programs in the "sl3/demo" directory and the test programs in the "sl3/test" directory to get a feel for acquiring the appropriate credentials for your application. The demonstration (sl3/demo) directories show a number of different scenarios:

tcp-hello

This directory contains client and server programs that illustrate the use of the SL3TCPIP Argument Builder in the SL3TCPIP module for acquiring TCPIP Transport Credentials. You need TCPIP Credentials in order to communicate with plain IIOP objects, such as a NamingService, etc.

tls-hello

This directory contains client and server programs that illustrate the use of the Argument Builder in the SL3TLS module for acquiring CSIv1 TLS Transport Credentials. It uses Java KeyStores for initialization information. You need TLS Credentials if you are communicating with legacy CSIv1 TLS/SSL objects. You are encouraged to use Security Level 3 Credentials (using TLS) for new objects, which are shown by the tls-csiv2 demo.

krb-hello

This directory contains client and server programs that illustrate the use of the Argument Builder in the SL3KRB5 module for acquiring CSIv1 Kerberos Credentials. You need Kerberos Credentials if you are communicating with legacy CSIv1 Kerberos objects. You are encouraged to use Security Level 3 Credentials (using Kerberos) for new objects, which are shown by the krb-sl3 demo.

krb-del

This directory contains client, relay, and server programs that illustrate the use of the Argument Builder in the SL3KRB5 module for acquiring CSIv1 Kerberos Transport Credentials, such that the client acquires Kerberos Credentials and "embodies" the relay to act on the server in the client's behalf.

tls-csiv2

This directory contains client and server programs that illustrate the use of the Argument Builders in the SL3TLS and SL3CSI modules that in concert acquire Security Level 3 Credentials using TLS. If you are creating new objects, you are encouraged to use this method.

krb-sl3

This directory contains client and server programs that illustrate the use of the Argument Builders in the SL3KRB5 and SL3CSI modules that in concert acquire Security Level 3 Credentials using Kerberos. If you are creating new objects, you are encouraged to use this method.

sl3-krb-u2u

This directory contains client and server programs that illustrate the use of the Argument Builders in SL3KRB5 and SL3CSI modules that in concert acquire Security Level 3 Credentials using Kerberos, but with the standard User-to-User version of the GSS-Kerberos protocol. This version of the protocol allows you to set up CORBA objects (i.e. servers) with just using the Kerberos session cache file. In this case, a user can start up a CORBA server merely from his login, using the Kerberos login program, "kinit". With the normal Kerberos protocol, you needed to supply the password, either by prompt or hardwire, to the software, or use a Kerberos keytab file, of which many Kerberos installations will not allow you to have.

quote-hello

This directory contains client and server programs that illustrate the acquisition of Security Level 3 Credentials that use the CSIv2 protocol such that the client "quotes" a particular principal that is different than its own.

user-pass

This directory contains client and server programs that illustrate the acquisition of Security Level 3 Credentials that use the CSIv2 protocol to do "User Password" client authentication. There are several examples that show the use of user-password over anonymous protected TLS, and plain TCPIP.

trust-hello

This directory contains client and server programs that illustrate the acquisition of Security Level 3 Credentials such that the client makes a trust decision based on the target's transport principal before any CSIv2 data is transmitted to the target. Such an approach is vital in when using User-Password, as a spoof IOR can extract user password information from the client.

tls-tcp-relay

This directory contains client, relay, and server programs that illustrate the use of creating Security Level 3 Credentials on the fly. The Client uses Transport Security TLS credentials, as in demo/tls-hello. The relay object creates Security Level 3 "quoting" Credentials, as in "demo/quote-hello" that quotes the clients TLS identity over TCPIP. The relay object then uses these credentials to make a request on the server, which is a CSIv2 enabled over TCPIP.

naming-demo

This directory contains client and server programs that show what you have to do when using a plain IIOP based CORBA Naming Service along with protected communication. It shows acquiring Transport Security Credentials using TCPIP for making invocations on the Naming Service, and using Security Level 3 Credentials using TLS for making invocations on the Server.

access-hello

This directory contains client and server programs that show you a way to perform access control based on the information in the client's credentials. The server has an access decision object which implements a simple security policy. When the server gets an invocation from the client, the target object calls the access decision function with the client's principal, and performs or denies the request accordingly.

access-intercept

This directory contains client and server programs that show you a way to perform access control based on the information in the client's credentials. It is the same demonstration that is in the "access-hello" demonstration. However, this demonstration shows you a way to perform the access decision via a standard CORBA Portable Request Interceptor. The server object is "security unaware" in the fact that it does not check access. The access check is performed by an interceptor. When the server gets an invocation from the client, the invocation is intercepted and the interceptor calls the access decision function with the client's principal, and performs or denies the request accordingly.

atlas-hello

This directory shows you how to deploy an "authorization context", using the SL3CSI Argument Builder options. An authorization context allows you to specify an ATLAS (Authorization Token Layer Acquisition Service) in which the client retrieves authorization information from the server's ATLAS. The example has a simple ATLAS and a simple Authorization Element format.

web-hello

This directory shows you how to get a TLS identity from an HTTPS connection made from a browser and use Security Level 3 "quoting" Credentials over TCPIP, as in "quote-hello", to make an invocation on a server using the web browser's TLS identity.

Module Index

SecurityLevel3

The Security Level 3 Module contains the API that is used to acquire and examine credentials of the CSI and Transport Layers. Most Applications will use these interfaces. You acquire Security Level 3 Credentials using the Security Level 3 Credentials Curator with an Argument generated by the Argument Builder in the SL3CSI module.

TransportSecurity

The Transport Security Module contains the API that is used to acquire and examine CSIv1 Credentials. These Credentials represent security attributes of the transport layer. You acquire Transport Security Credentials using the Transport Security Credentials Curator with an Argument generated by the Argument Builders in the SL3TCPIP, SL3TLS, and SL3KRB5 modules.

SecurityLevel3Transport

The Security Level 3 Transport Module contains extensions to Security Level 3 Credentials interfaces that give access to the underlying Transport Security credentials.

SL3TCPIP

This module contains the SL3TCPIP Argument Factory and Argument Builder to handle options that configure the end points of TCP/IP connections, such as port numbers, IP addresses, backlog, etc.

SL3TLS

This module contains the TLS Argument Factory and Argument Builder to handle options that configure the end points of a TLS/SSL connection, such as getting certificates and private keys from Java KeyStore files, and all the TCP/IP options as well.

SL3KRB5

This module contains the SL3KRB5 Argument Factory and Argument Builder to handle options that configure the end points of a SECIOP-GSS Kerberos connection, such as the location of the Kerberos credential cache, Kerberos keytab, and all the TCP/IP options as well.

SL3CSI

This module contains the SL3CSI Argument Factory and Argument Builder to handle options that are CSIv2 related, such as adding a Username/Password Processor (UserPassword), asserting a different principal, adding a TrustInServerDecider (Trust), or adding an authorization context (SL3Authorization).

UserPassword

This module contains two valuetypes used to implement the UserPassword CSIv2 Client Authentication protocol.

Trust

This module contains the necessary TrustInServerDecider interface that is used by the client in deciding whether a target is trusted before the ORB starts sending any GIOP requests.

SL3Authorization

This module contains the necessary interfaces for dealing with ATLAS and the processing of the tokens delivered by the CSIv2 protocol.

SL3AQArgs

The SL3AQArgs Module contains the object and operations that help in the building of the complex arguments needed to acquire credentials. It contains the base interface for the Argument Factory and Argument Builder. It's Argument Factory and Argument Builders are extended by other modules to facilitate building argument for those particular services, such as SL3CSI, SL3TLS, SL3KRB5, and SL3TCPIP.

ATLAS

This module is the OMG Authorization Token Layer Acquisition Service (ATLAS) IDL file.
